Specialist design & production of cable termination components
Standard copper-tube lugs and bespoke terminals
The world’s most exacting engineers choose LML’s application-led cable termination components. Designed to precise specifications, produced in-house using next-generation tooling and delivered faster than the competition, we’ll keep your project on track.
Benefits of our cable termination components
- Technical & design support drawing on a half-century’s experience
- Full range of advanced machining processes for custom components
- Application-led design for HV, buried connections & more
- Fine-detail cutting options including waterjet & fibre-laser
- All custom cable terminations & pins designed, produced & delivered from our UK workshop
- Trusted suppliers of cable termination components, delivering bespoke products faster
Custom cable termination components
LML Products has the expertise and in-house machinery to create custom cable termination components for the most demanding projects. Discover more about our standard and bespoke products by clicking the photo opposite.
Our cable termination components
The simplest of concepts with the broadest of applications, a crimped copper tube provides reliable entry and exit for current to be conducted via a cable.
As a cable termination, the crimped copper-tube cable epitomises the elegance of conceptual simplicity whether used as a lug with fastener-hole or pin-terminated for insertion. They can also be supplied custom-specified with extended or angled-palms, multiple holes, slots, or brazed attachments.
The high thermal and electrical conductivity of copper mean that the mass of attached cable dominates temperature regulation under normal working current conditions whilst an electroplated tin-coating stabilises contact resistance. More extreme or specialised applications may require a thicker wall for mechanical integrity or alternative coatings to cables and terminations. Nickel prevents allotropic tin-powder at very low temperatures, and silver prevents the irreversible extreme resistance-damage caused by diffusion of tin or nickel at very high temperatures.
Properly specified crimps, cables and terminations should have no problem with thermal-cycle endurance tests (such as EN61238). More comprehensive design and assembly specifications are necessary to guarantee the performance required for compliance with tests for portable earthing (EN61138) and for short-circuit and earth connections whilst live-working (EN61230). Note, however, that these qualifications apply to the combination of terminal, cable and crimping process including tooling. They are not otherwise transferable; a good quality terminal might contribute to an inadequate termination if, for example, poorly crimped to an inappropriate cable.
Volume applications to equipment and machinery are best covered by LML’s custom cables and braids which are terminated under factory conditions and supplied with pre-specified insulation, terminals and identification-labelling. LML complements its standard range of own-manufacture cable termination components with an extensive range of specialised versions and an infinite range of design possibilities.
Image Title
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Pellentesque ac auctor tellus. In finibus sollicitudin massa, quis ultrices sem volutpat quis. Mauris nec pellentesque nibh, sed dictum dui.
Donec eu tellus non ante posuere elementum egestas sit amet enim. Nulla dui dui, gravida non euismod sed, tempor fermentum leo.
Maecenas vitae convallis tortor. Nullam nec enim lorem. Cras blandit rutrum ante ut laoreet. Quisque dignissim, risus eu congue maximus, nisl ante luctus mauris, nec efficitur mi mi vitae ligula. Pellentesque fermentum nunc vitae orci maximus blandit. Integer nulla diam, rutrum ac vestibulum sit amet, mattis nec magna. Donec ut tempus.
Image Title
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Pellentesque ac auctor tellus. In finibus sollicitudin massa, quis ultrices sem volutpat quis. Mauris nec pellentesque nibh, sed dictum dui.
Donec eu tellus non ante posuere elementum egestas sit amet enim. Nulla dui dui, gravida non euismod sed, tempor fermentum leo.
Maecenas vitae convallis tortor. Nullam nec enim lorem. Cras blandit rutrum ante ut laoreet. Quisque dignissim, risus eu congue maximus, nisl ante luctus mauris, nec efficitur mi mi vitae ligula. Pellentesque fermentum nunc vitae orci maximus blandit. Integer nulla diam, rutrum ac vestibulum sit amet, mattis nec magna. Donec ut tempus.
Image Title
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Pellentesque ac auctor tellus. In finibus sollicitudin massa, quis ultrices sem volutpat quis. Mauris nec pellentesque nibh, sed dictum dui.
Donec eu tellus non ante posuere elementum egestas sit amet enim. Nulla dui dui, gravida non euismod sed, tempor fermentum leo.
Maecenas vitae convallis tortor. Nullam nec enim lorem. Cras blandit rutrum ante ut laoreet. Quisque dignissim, risus eu congue maximus, nisl ante luctus mauris, nec efficitur mi mi vitae ligula. Pellentesque fermentum nunc vitae orci maximus blandit. Integer nulla diam, rutrum ac vestibulum sit amet, mattis nec magna. Donec ut tempus.
Image Title
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Pellentesque ac auctor tellus. In finibus sollicitudin massa, quis ultrices sem volutpat quis. Mauris nec pellentesque nibh, sed dictum dui.
Donec eu tellus non ante posuere elementum egestas sit amet enim. Nulla dui dui, gravida non euismod sed, tempor fermentum leo.
Maecenas vitae convallis tortor. Nullam nec enim lorem. Cras blandit rutrum ante ut laoreet. Quisque dignissim, risus eu congue maximus, nisl ante luctus mauris, nec efficitur mi mi vitae ligula. Pellentesque fermentum nunc vitae orci maximus blandit. Integer nulla diam, rutrum ac vestibulum sit amet, mattis nec magna. Donec ut tempus.
Image Title
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Pellentesque ac auctor tellus. In finibus sollicitudin massa, quis ultrices sem volutpat quis. Mauris nec pellentesque nibh, sed dictum dui.
Donec eu tellus non ante posuere elementum egestas sit amet enim. Nulla dui dui, gravida non euismod sed, tempor fermentum leo.
Maecenas vitae convallis tortor. Nullam nec enim lorem. Cras blandit rutrum ante ut laoreet. Quisque dignissim, risus eu congue maximus, nisl ante luctus mauris, nec efficitur mi mi vitae ligula. Pellentesque fermentum nunc vitae orci maximus blandit. Integer nulla diam, rutrum ac vestibulum sit amet, mattis nec magna. Donec ut tempus.
Image Title
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Pellentesque ac auctor tellus. In finibus sollicitudin massa, quis ultrices sem volutpat quis. Mauris nec pellentesque nibh, sed dictum dui.
Donec eu tellus non ante posuere elementum egestas sit amet enim. Nulla dui dui, gravida non euismod sed, tempor fermentum leo.
Maecenas vitae convallis tortor. Nullam nec enim lorem. Cras blandit rutrum ante ut laoreet. Quisque dignissim, risus eu congue maximus, nisl ante luctus mauris, nec efficitur mi mi vitae ligula. Pellentesque fermentum nunc vitae orci maximus blandit. Integer nulla diam, rutrum ac vestibulum sit amet, mattis nec magna. Donec ut tempus.
Technical Specifications
The numerical part of the series reference denotes the conductor cross sectional area in mm2. Thus to order, for example, a terminal for a 10mm2 conductor and a M12 stud size the full ordering reference is CAT10-12.
Technical specification chart
Find the optimum component for your application right here.
View ChartTechnical specification chart
LML Product brochure
Find all our cable termination components – and the rest of our range – in the latest LML Product Brochure.
Download
Related Products
Related Electrical Pins Articles
Make an enquiry
LML Products is the most trusted supplier of busbar, cable, connector & earth bar in the UK. We’re ready to talk about your project.
Or Call: 01249 810000
